Product Description
Small top plate caster with extreme capacity. Rugged rigid construction with 5" x 2" metal wheel offers a 1000 pound capacity with low height and the ability to function in 24/7 operations.- 5" x 2" metal wheel
- 1000 pound capacity
- 1/4" thick top plate
- 1/4" thick legs
- Mounting height: 6.1875"
- Powder Coated with a metallic HAA polyester
- Temperature range: -40°F to 320°F
- Chemical Resistance: Medium
The endurance series only dimensional difference lies in its wheel width and leg thickness. To achieve a higher load rating and durablility, Endurance features two-inch wide wheels and 1/4" thick legs (other brands have 1-1.4" wide wheels). You'll pay more up front for its premium construction and ultra-rugged design, then reap the savings in the long run while it runs and runs without breaking a sweat. Endurance is intentionally designed and over-engineered for applications where replacement is cost prohibitive.
Product Videos
Custom Field
Caster Type Rigid
Wheel Diameter 5"
Tread Width 2"
Brake No
Mounting Type Top Plate
Mounting Size 2-1/2" x 3-5/8"
Bolt Hole Pattern 1-3/4" x 2-7/16" to 1-3/4" x 3"
Wheel Material Cast Iron
Overall Height 6-3/16"
Load Capacity 1,000 lbs
Finish Zinc
Wheel Bearing Sealed Precision Ball Bearings
