Product Description
- Hamilton 10" dual wheel ground support rigid caster
- Two 10" x 4" tires (400 x 6) with tapered bearings
- 2,000-pound capacity
- 12-1/4" mounting height
- 4-1/2" x 6-1/4" top plate
- 2-7/16" x 4-15/16" slotted to 3-3/8" x 5-1/4" bolt hole pattern
- Drop forged steel mounting plate and horn construction
- Red enamel finish
- Unit weight: 55 lbs.
- Lead time 1-2 weeks
Product Videos
Custom Field
Caster Type Rigid
Wheel Diameter 10"
Tread Width 4"
Brake No
Mounting Type Top Plate
Mounting Size 4-1/2" x 6-1/4"
Bolt Hole Pattern 2-7/16" x 4-15/16" to 3-3/8" x 5-1/4"
Wheel Material Pneumatic
Overall Height 12-1/4"
Load Capacity 2,000 lbs
Finish Zinc
Wheel Bearing Tapered Roller Bearing
