Product Description
LKX-SPO 127XK Stainless Steel Total Lock Caster
125mm x 50mm heavy duty white nylon wheel with stainless steel ball bearings
1,650 pound capacity
170mm height (6.69")
140mm x 110 mm top plate (5.51" x 4.33")
105mm x 75-80mm bolt hole pattern (4.13" x 2.95"-3.15")
Rigs are made of heavy pressed high-quality, chromium-nickel stainless steel (Material No. 1.4301/AISI 304). Swivel bracket with double ball bearing in the swivel head, strong central kingpin, swivel head seals. The special Blickle dynamic riveting process of the swivel head results in minimal swivel head play and smooth rolling characteristics with an increased service life achieved by the work hardening of the ball race grooves.
Manufactured in Germany and stocked in the USA.
Product Videos
Custom Field
Caster Type Swivel
Wheel Diameter 127mm
Tread Width 50mm
Brake Yes
Mounting Type Top Plate"
Mounting Size 110mm x 140mm
Bolt Hole Pattern 60mm x 80mm
Wheel Material Nylon
Overall Height 170mm;Load Capacity=1,650 lbs"
Finish Stainless Steel
Wheel Bearing Stainless Steel Ball Bearing
