Product Description
D4.08109.839 HT SS WB29
- 8" Colson Defender swivel caster
- 8" x 2" Thermo Hi-Temp Wheel
- Stainless steel roller bearings
- 1100 pound capacity
- 9-1/2" mounting height
- 4" x 4-1/2" top plate
- 3" x 3" x 2-5/8" x 3-5/8" bolt hole pattern
- Polished 304 stainless steel
- 1/4" Thick top plate and legs
- Ideal for wash down and sanitary applications
- -70°F to +480°F temperature range
CAD DRAWINGS
Product Videos
Custom Field
Caster Type Swivel
Wheel Diameter 8"
Tread Width 2"
Brake No
Mounting Type Top Plate
Mounting Size 4" x 4-1/2"
Bolt Hole Pattern 3" x 3" to 2-5/8" x 3-5/8"
Wheel Material High Temperature
Overall Height 9-1/2"
Load Capacity 1,100 lbs
Finish Stainless
Wheel Bearing Roller Bearing
