Product Description
Economical Heavy Duty Swivel Caster
8" x 3" green tread polyurethane on cast iron wheel
Roller bearings in wheel
2,000 pound capacity
10-1/8" mounting height
4-3/8" swivel radius
4-1/2" x 6-1/4" top plate
2-7/16" x 4-15/16" slotted to 3-3/8" x 5-1/4" bolt hole pattern
Drop forged (ASTM 1045) construction
Zinc plated
This caster's swivel section is made from ASTM 1045 steel, drop forged and
hardened. 3/8" thick top plate with 3-3/8" hardened load raceways precisely
machined deep-groove with 7/16" hardened steel ball bearings for thrust force.
3/4" heat treated kingpin is used to enhance the load capacity.
Legs are made from 3/8" thick steel robotically welded on both sides
for maximum strength.
hardened. 3/8" thick top plate with 3-3/8" hardened load raceways precisely
machined deep-groove with 7/16" hardened steel ball bearings for thrust force.
3/4" heat treated kingpin is used to enhance the load capacity.
Legs are made from 3/8" thick steel robotically welded on both sides
for maximum strength.
Product Videos
Custom Field
Caster Type Swivel
Wheel Diameter 8"
Tread Width 3"
Brake No
Mounting Type Top Plate
Mounting Size 4-1/2" x 6-1/4"
Bolt Hole Pattern 2-7/16" x 4-15/16" to 3-3/8" x 5-1/4"
Wheel Material Polyurethane
Overall Height 10-1/8"
Load Capacity 2,000 lbs
Finish Zinc
Wheel Bearing Roller Bearing
