Product Description
- 4" Total lock swivel caster
- 4" x 1-1/4" maroon polyurethane tread on gray core wheel
- Annular ball bearings in wheel
- 350 pound load rating
- Front mounted brake locks wheel and swivel section
- 5-1/16" mounting height
- 3-9/16" swivel radius
- 2-3/8" x 3-5/8" top plate
- 1-3/4" x 2-7/8" to 3" bolt hole pattern
- Zinc plate finish
The locking mechanism is at the leading side of the caster. This design eliminates the extended swivel radius found on most total lock casters.
Product Videos
Custom Field
Caster Type Swivel
Wheel Diameter 4"
Tread Width 1-1/4"
Brake Yes
Mounting Type Top Plate
Mounting Size 2-3/8" x 3-5/8"
Bolt Hole Pattern 1-3/4" x 2-7/8" to 1-3/4" x 3"
Wheel Material Polyurethane
Overall Height 5-1/16"
Load Capacity 350 lbs
Finish Zinc
Wheel Bearing Ball Bearing
