Product Description
- 4" medium-duty swivel caster with brake
- 4" x 2" solid blue urethane wheel with roller bearings
- Wheel durometer 60 Shore
- 750-pound capacity
- 5-5/8" overall height
- 4" x 4-1/2" top plate
- 3" x 3" slotted to 2-5/8" x 3-5/8" bolt hole pattern
- 3-1/4" swivel radius
- RoHS zinc plate finish
Wheel properties:
- Solid cast polyurethane elastomer eliminates bonding failures
- 100% washable and steam cleanable
- Not affected by grease, oils, most chemicals & cleaning solutions
- Resists compression set or "flat spotting".
- Temperature range: -50°F to 180°F
Product Videos
Custom Field
Caster Type Swivel
Wheel Diameter 4"
Tread Width 2"
Brake Yes
Mounting Type Top Plate
Mounting Size 4" x 4-1/2"
Bolt Hole Pattern 3" x 3" to 2-5/8" x 3-5/8"
Wheel Material Polyurethane
Overall Height 5-5/8"
Load Capacity 750 lbs
Finish Zinc
Wheel Bearing Roller Bearing
