Product Description
|
10" x 3" Forged Steel wheel with roller bearings
Rigid Caster 5400 lbs load capacity 12-1/2" overall height 5" x 7-1/4" Top Plate 3-3/8" x 5-1/4" slotted to 4-1/8" x 6-1/8" bolt hole pattern
5/16" AISI 1045 heat treated steel Standard lead time is 14 days.
Used for Conveyor-drawn tow trucks, heavy duty bakery racks, production dollies, heavy duty dough troughs, etc.
|
CAD DRAWINGS
Product Videos
Custom Field
Caster Type Rigid
Wheel Diameter 10"
Tread Width 3"
Brake No
Mounting Type Top Plate
Mounting Size 5" x 7-1/4"
Bolt Hole Pattern 3-3/8" x 5-1/4" to 4-1/8" x 6-1/8"
Wheel Material Forged Steel
Overall Height 12-1/2"
Load Capacity 5,400 lbs
Finish Zinc
Wheel Bearing Roller Bearing
