Product Description
- Albion rigid caster
- 6" x 2" forged steel wheel with roller bearings
- 1,250 pound capacity
- 7-1/4" mounting height
- 4" x 4-1/2" top plate
- 3" x 3" slotted to 2-5/8" x 3-5/8" bolt hole pattern
- Wheel hardness: Rockwell 80 B
- Cold forged 1/4" thick top plate & legs
- RoHS compliant zinc finish
16 Series casters are cold formed, heat treated steel and recommended for medium to medium heavy duty applications.
Drop forged steel wheels are hot forged from carbon steel billets. The forging process improves grain flow, enhances ductility and tensile strength. Suitable for high capacity, abusive applications.
Product Videos
Custom Field
Caster Type Rigid
Wheel Diameter 6"
Tread Width 2"
Brake No
Mounting Type Top Plate
Mounting Size 4" x 4-1/2"
Bolt Hole Pattern 3" x 3" to 2-5/8" x 3-5/8"
Wheel Material Forged Steel
Overall Height 7-1/4"
Load Capacity 1,250 lbs
Finish Zinc
Wheel Bearing Roller Bearing
