Blickle LH 14/16 Series

Blickle Logo

LH 14/16 Series

Heavy duty industrial top plate casters with capacities up to 2,000 lbs.  RoHs Compliant

LH castor bracket series features heavy pressed steel parts, heavy fork and top plate, double
ball bearing in the swivel head, four hardened bearing seats, very strong bolted and secured
central kingpin.  Minimum wear at high loads.  Particularly insensitive to shock and impact
loads. Maintenance free, lubricated with long-life grease.

The LH rig series with top plate fitting are available with the following wheels:


ALEV Elastic Rubber wheel
Tread: High-quality elastic solid rubber in smooth
rolling quality 'Blickle EasyRoll', 65 shore A, black,
vulcanized tire.
Wheel Center: Die-cast aluminum
Bearing Type: Ball bearing


SPOG nylon wheels Tread: High-quality impact-resistant nylon,
vey rugged, extra heavy wheel design, 70 shore D,
gray.
Bearing Type: Ball bearing

POTH Thermoplastic Polyurethane

Tread: High-quality thermoplatstic polyurethane
(TPU), 94 shore A, dark gray, non-marking,
non-staining, chemically bonded.
Wheel:
Impact-resistant nylon, natural white.
Bearing Type: Ball bearing.

GSPO Nylon Wheels
Tires:  High-quality, impact resistant, hard and
tough, highly compressed cast nylon, 80 shore D,
natural beige.
Bearing type: Ball bearing.

ALST polyurethane wheels

Tread: High-quality polyurethane-elastomer
Blickle Softhane®, 75 shore A, green,
non-marking, non-staining. Cast Tread.
Wheel:
Die-cast aluminum.
Bearing Type: Ball bearing.

ALTH Polyurethane Wheels Tread: High-quality polyurethane-elastomer
Blickle Extrathane®, 92 shore A, light brown,
non-marking, non-staining. Cast Tread.
Wheel:
Die-cast aluminum.
Bearing Type: Ball bearing.
ALBS Poly wheels Tread: High-quality polyurethane-elastomer
Blickle Besthane®, 75 shore A, blue,
non-marking, non-staining. Cast Tread.
Wheel:
Die-cast aluminum
Bearing Type: Ball bearing.
GTH Poly Wheels Tread: High-quality polyurethane-elastomer
Blickle Extrathane®, 92 shore A, light brown,
non-marking, non-staining. Cast Tread.
Wheel:
Rugged gray cast iron, lacquered, silver.
Bearing Type: Ball bearing.


For mor information view our catalog page

Displaying products 1 - 30 of 96 results
Page 1 of 4 Page 1234movenext
LH-ALEV 125K-14 Blickle 5
LH-ALEV 100K-14 Blickle 4" Swivel Caster ALEV Wheel Plate Ball Bearing-1
Your Price: $71.17
LH-ALEV 100K-14 Blickle 4" Swivel Caster ALEV Wheel Plate Ball Bearing-1

4 x 1 9/16 ALEV Wheel Swivel Plate Caster Ball bearing 550 lbs capacity

LH-ALEV 100K-14-FI Blickle 4
LH-ALEV 100K-14-FI Blickle 4" Swivel Caster ALEV Wheel Plate Ball Bearing Brake
Your Price: $93.96
LH-ALEV 100K-14-FI Blickle 4" Swivel Caster ALEV Wheel Plate Ball Bearing  Brake

4 x 1 9/16 ALEV Wheel Swivel Plate Caster With Stop Fix Brake Ball bearing 440 lbs capacity

BHS-ALEV 100K-14 Blickle 4
BHS-ALEV 100K-14 Blickle 4" Rigid Caster ALEV Wheel Plate Ball Bearing
Your Price: $40.09
BHS-ALEV 100K-14 Blickle 4" Rigid Caster ALEV Wheel Plate  Ball Bearing

4 x 1 9/16 ALEV Wheel Rigid Plate Caster Ball bearing 440 lbs capacity

LH-ALEV 125K-14 Blickle 5
LH-ALEV 125K-14 Blickle 5" Swivel Caster ALEV Wheel Plate Ball Bearing
Your Price: $80.53
LH-ALEV 125K-14 Blickle 5" Swivel Caster ALEV Wheel Plate Ball Bearing

5 x 1 9/16 ALEV Wheel Swivel Plate Caster Ball bearing 550 lbs capacity

LH-ALEV 125K-14-FI Blickle 5
LH-ALEV 125K-14-FI Blickle 5" Swivel Caster ALEV Wheel Plate Ball Bearing Brake
Your Price: $99.24
LH-ALEV 125K-14-FI Blickle 5" Swivel Caster ALEV Wheel Plate Ball Bearing  Brake

5 x 1 9/16 ALEV Wheel Swivel Plate Caster With Stop Fix Brake Ball bearing 550 lbs capacity

BHS-ALEV 125K-14 Blickle 5
BHS-ALEV 125K-14 Blickle 5" Rigid Caster ALEV Wheel Plate Ball Bearing
Your Price: $44.16
BHS-ALEV 125K-14 Blickle 5" Rigid Caster ALEV Wheel Plate  Ball Bearing

5 x 1 9/16 ALEV Wheel Rigid Plate Caster Ball bearing 550 lbs capacity

LH-ALEV 150K-16 Blickle 6
LH-ALEV 150K-16 Blickle 6" Swivel Caster ALEV Wheel Plate Ball Bearing
Your Price: $116.57
LH-ALEV 150K-16 Blickle 6" Swivel Caster ALEV Wheel Plate Ball Bearing

6 x 2 1/8 ALEV Wheel Swivel Plate Caster Ball bearing 880 lbs capacity

LH-ALEV 150K-16-FI Blickle 6
LH-ALEV 150K-16-FI Blickle 6" Swivel Caster ALEV Wheel Plate Ball Bearing Brake
Your Price: $147.34
LH-ALEV 150K-16-FI Blickle 6" Swivel Caster ALEV Wheel Plate Ball Bearing  Brake

6 x 2 1/8 ALEV Wheel Swivel Plate Caster With Stop Fix Brake Ball bearing 880 lbs capacity

BHS-ALEV 150K-16 Blickle 6
BHS-ALEV 150K-16 Blickle 6" Rigid Caster ALEV Wheel Plate Ball Bearing
Your Price: $74.56
BHS-ALEV 150K-16 Blickle 6" Rigid Caster ALEV Wheel Plate Ball Bearing

6 x 2 1/8 ALEV Wheel Rigid Plate Caster Ball bearing 880 lbs capacity

LH-ALEV 200K-16 Blickle 8
LH-ALEV 200K-16 Blickle 8" Swivel Caster ALEV Wheel Plate Ball Bearing
Your Price: $126.28
LH-ALEV 200K-16 Blickle 8" Swivel Caster ALEV Wheel Plate Ball Bearing

8 x 2 ALEV Wheel Swivel Plate Caster Ball bearing 1100 lbs capacity

LH-ALEV 200K-16-FI Blickle 8
LH-ALEV 200K-16-FI Blickle 8" Swivel Caster ALEV Wheel Plate Ball Bearing Brake
Your Price: $157.12
LH-ALEV 200K-16-FI Blickle 8" Swivel Caster ALEV Wheel Plate Ball Bearing  Brake

8 x 2 ALEV Wheel Swivel Plate Caster With Stop Fix Brake Ball bearing 1100 lbs capacity

BHS-ALEV 200K-16 Blickle 8
BHS-ALEV 200K-16 Blickle 8" Rigid Caster ALEV Wheel Plate Ball Bearing
Your Price: $82.97
BHS-ALEV 200K-16 Blickle 8" Rigid Caster ALEV Wheel Plate  Ball Bearing

8 x 2 ALEV Wheel Rigid Plate Caster Ball bearing 1100 lbs capacity

LH-POTH 100K-14 Blickle 4
LH-POTH 100K-14 Blickle 4" Swivel Caster POTH Wheel Plate Ball Bearing
Your Price: $70.32
LH-POTH 100K-14 Blickle 4" Swivel Caster POTH Wheel Plate Ball Bearing

4 x 1 3/8 POTH Wheel Swivel Plate Caster Ball bearing 660 lbs capacity

LH-POTH 100K-14-FI Blickle 4
LH-POTH 100K-14-FI Blickle 4" Swivel Caster POTH Wheel Plate Ball Brake
Your Price: $89.10
LH-POTH 100K-14-FI Blickle 4" Swivel Caster POTH Wheel Plate Ball Brake

4 x 1 3/8 POTH Wheel Swivel Plate Caster With Brake Ball bearing 660 lbs capacity

BHS-POTH 100K-14 Blickle 4
BHS-POTH 100K-14 Blickle 4" Rigid Caster POTH Wheel Plate Ball Bearing
Your Price: $35.41
BHS-POTH 100K-14 Blickle 4" Rigid Caster POTH Wheel Plate Ball Bearing

4 x 1 3/8 POTH Wheel Rigid Plate Caster Ball bearing 660 lbs capacity

 LH-POTH 125K-14 Blickle 4
LH-POTH 125K-14 Blickle 4" Swivel Caster POTH Wheel Plate Ball Bearing
Your Price: $74.69
LH-POTH 125K-14 Blickle 4" Swivel Caster POTH Wheel Plate Ball Bearing

5 x 1 9/16 POTH Wheel Swivel Plate Caster Ball bearing 770 lbs capacity

 LH-POTH 125K-14-FI Blickle 5
LH-POTH 125K-14-FI Blickle 5" Swivel Caster POTH Wheel Plate Ball Brake
Your Price: $93.52
LH-POTH 125K-14-FI Blickle 5" Swivel Caster POTH Wheel Plate Ball Brake

5 x 1 9/16 POTH Wheel Swivel Plate Caster With Brake Ball bearing 770 lbs capacity

BHS-POTH 125K-14 Blickle 5
BHS-POTH 125K-14 Blickle 5" Rigid Caster POTH Wheel Plate Ball Bearing
Your Price: $38.62
BHS-POTH 125K-14 Blickle 5" Rigid Caster POTH Wheel Plate Ball Bearing

5 x 1 9/16 POTH Wheel Rigid Plate Caster Ball bearing 770 lbs capacity

LH-POTH 150K-16 Blickle 6
LH-POTH 150K-16 Blickle 6" Rigid Caster POTH Wheel Plate Ball Bearing
Your Price: $109.08
LH-POTH 150K-16 Blickle 6" Rigid Caster POTH Wheel Plate  Ball Bearing

6 x 1 3/4 POTH Wheel Swivel Plate Caster Ball bearing 1100 lbs capacity

LH-POTH 150K-16 Blickle 6
LH-POTH 150K-16-FI Blickle 6" Rigid Caster POTH Wheel Plate Ball Bearing Brake
Your Price: $139.87
LH-POTH 150K-16-FI Blickle 6" Rigid Caster POTH Wheel Plate Ball Bearing Brake

6 x 1 3/4 POTH Wheel Swivel Plate Caster With Brake Ball bearing 1100 lbs capacity

LH-POTH 200K-16 Blickle 8
LH-POTH 200K-16 Blickle 8" Swivel Caster POTH Wheel Plate Ball Bearing
Your Price: $121.85
LH-POTH 200K-16 Blickle 8" Swivel Caster POTH Wheel Plate  Ball Bearing

8 x 2 POTH Wheel Swivel Plate Caster Ball bearing 1760 lbs capacity

LH-POTH 200K-16 Blickle 8
LH-POTH 200K-16-FI Blickle 8" Swivel Caster POTH Wheel Plate Ball Bearing brake
Your Price: $152.74
LH-POTH 200K-16-FI Blickle 8" Swivel Caster POTH Wheel Plate Ball Bearing brake

8 x 2 POTH Wheel Swivel Plate Caster with Brake Ball bearing 1760 lbs capacity

BHS-POTH 200K-16 Blickle 8
BHS-POTH 200K-16 Blickle 8" Rigid Caster POTH Wheel Plate Ball Bearing
Your Price: $78.60
BHS-POTH 200K-16 Blickle 8" Rigid Caster POTH Wheel Plate  Ball Bearing

8 x 2 POTH Wheel Rigid Plate Caster Ball bearing 1760 lbs capacity

LH-SPOG 80K-14 Blickle 4
LH-SPOG 80K-14 Blickle 3" Swivel Caster SPOG Wheel Plate Ball Bearing
Your Price: $70.39
LH-SPOG 80K-14 Blickle 3" Swivel Caster SPOG Wheel Plate Ball Bearing

3 1/8 x 1 7/16 SPOG Wheel Swivel Plate Caster Ball bearing 770 lbs capacity

LH-SPOG 80K-14-FI Blickle 4
LH-SPOG 80K-14-FI Blickle 3" Swivel Caster SPOG Wheel Plate Ball Brake
Your Price: $89.17
LH-SPOG 80K-14-FI Blickle 3" Swivel Caster SPOG Wheel Plate Ball Brake

3 1/8 x 1 7/16 SPOG Wheel Swivel Plate Caster Ball bearing 770 lbs capacity

BHS-SPOG 80K-14 Blickle 4
BHS-SPOG 80K-14 Blickle 4" Rigid Caster SPOG Wheel Plate Ball Bearing
Your Price: $36.17
BHS-SPOG 80K-14 Blickle 4" Rigid Caster SPOG Wheel Plate Ball Bearing

3 1/8 x 1 7/16 SPOG Wheel Rigid Plate Caster Ball bearing 770 lbs capacity

LH-SPOG 100K-14 Blickle 4
LH-SPOG 100K-14 Blickle 4" Swivel Caster SPOG Wheel Plate Ball Bearing
Your Price: $76.01
LH-SPOG 100K-14 Blickle 4" Swivel Caster SPOG Wheel Plate Ball Bearing

4 x 1 7/16 SPOG Wheel Swivel Plate Caster Ball bearing 1100 lbs capacity

LH-SPOG 100K-14-FI Blickle 4
LH-SPOG 100K-14-FI Blickle 4" Swivel Caster SPOG Wheel Plate Ball Brake
Your Price: $94.64
LH-SPOG 100K-14-FI Blickle 4" Swivel Caster SPOG Wheel Plate Ball Brake

4 x 1 7/16 SPOG Wheel Swivel Plate Caster Ball bearing 1100 lbs capacity

BHS-SPOG 100K-14 Blickle 4
BHS-SPOG 100K-14 Blickle 4" Rigid Caster SPOG Wheel Plate Ball Bearing
Your Price: $40.70
BHS-SPOG 100K-14 Blickle 4" Rigid Caster SPOG Wheel Plate Ball Bearing

4 x 1 7/16 SPOG Wheel Rigid Plate Caster Ball bearing 1100 lbs capacity

 LH-SPOG 125K-14 Blickle 4
LH-SPOG 125K-14 Blickle 4" Swivel Caster SPOG Wheel Plate Ball Bearing
Your Price: $84.50
LH-SPOG 125K-14 Blickle 4" Swivel Caster SPOG Wheel Plate Ball Bearing

5 x 1 9/16 SPOG Wheel Swivel Plate Caster Ball bearing 1540 lbs capacity
